SQUARE CASES  Plain - Tables | CAD  •  Centerpost  •  Holes  •  Holes/standoffs  •  Open-end features  •  "T"  •  Misc.  SQUARE CASES
ROUND CASES  Plain - Tables | CAD  •  Centerpost  •  Holes  •  Holes/standoffs  •  Open-end features  •  "T"  •  Misc.  ROUND CASES
RECT. CASES  Plain - Tables | CAD  •  Centerpost  •  Holes  •  Holes/standoffs  •  Open-end features  •  "T"  •  Misc.  RECT. CASES
Bobbins  •  Dual-in-line headers  •  Surface mounts - One | Two | Three  •  Toroid mounts - One | Two | Three | Four | "Tombstone"

Located in San Marcos, CA, U.S.A., Plasmetex Industries attaches great importance to the quality of a mold. The majority of our molds are made in-house by skilled machinists and moldmakers. In-house moldmaking allows a close relationship between moldmaking and production departments, which ensures that preproduction and first article runs are accomplished with minimal (if any) delays.

For questions, please contact us. Our information is at the top right of the page.

  Moldmaking equipment includes CNC milling machines (left, Haas Automation) and electrical discharge machines (EDM, right, GF AgieCharmilles).

With total worldwide manufacturing space of more than 60,000 square feet, Plasmetex Industries offers a wide range of plastic parts for the electronics industry. These parts are standard or can be made according to customers' drawings. Materials used are in compliance with many international and domestic environmental regulations such as European RoHS and EPA SNURs.

  Plasmetex China facility

• Compression and transfer molding of thermosets
• Injection molding of thermoplastics
• Insert molding: Metallic terminals can be embedded in the plastic during molding or inserted after molding.
• Production sizes ranging from short runs to millions of pieces
• Secondary operations: Drill holes, cut cases to height, etc.

  Injection molding machine (ARBURG)

Catalog EC2 - Encapsulating Cases
• View plain cases online (single 3D view + tabulations all dimensions included)
• View other cases online (single 3D view + pdf all dimensions included)
• Request printed copy (all dimensions included)
• Please discard Catalog 2KC

Catalog TM2 - Toroid Mounts and more
• View parts online (multiple 3D views + basic dimensions only)
• Request printed copy (all dimensions included)

  Catalog TM2 cover

DAP data sheets:
• D72 from Cosmic Plastics

PPS data sheets:
• Ryton R-4 from Chevron Phillips
• Supec G401 from GE Plastics

Miscellaneous notes:
• Terminals can be supplied either lead-free (pure tinning) or with tin/lead plating.
• Unless otherwise specified, all dimensions are in inches.
• Unless otherwise specified, all drawings are made to scale.
